| TriggerForm: Serial Bus |
| Serial buses are defined in the Serial Tab. |
| When the Serial Bus Trigger mode is active, specific TriggerForms are provided for each serial bus type. |
|
| Trigger Bus |
| Select the specific bus from the Trigger Bus list... |
|
|
| Only one serial bus can trigger the logic analyzer. |
| Many serial buses can be captured and decoded together (even differing types). |
| Serial buses captured together are time-aligned and displayed together in the WaveForm view. |
| Each serial bus can be displayed in text format in the Serial Bus Text view. |
| A specific TriggerForm is provided for each serial bus type... |
| Trigger Bus: 1-Wire |
| Trigger Bus: CAN / CAN-FD |
| Trigger Bus: Clk+Data (bitstream) |
| Trigger Bus: DMX512 |
| Trigger Bus: I2C / I3C |
| Trigger Bus: I2S |
| Trigger Bus: JTAG |
| Trigger Bus: LIN |
| Trigger Bus: MDIO |
| Trigger Bus: ONFI |
| Trigger Bus: PWM Encoder |
| Trigger Bus: SDIO / MMC / eMMC |
| Trigger Bus: SENT |
| Trigger Bus: SPI |
| Trigger Bus: Quad-SPI / SPI-MIO |
| Trigger Bus: UART |
